Classified x HUNT 48 Limitless Aero Disc Wheelset

1501g Depth Width ext Width int size
48 mm 35 mm 22.5 mm 700c

The world's fastest disc brake wheels up to (and including) 50mm, featuring patented ultra-wide LIMITLESS technology, and built around the Classified PowerShift rear hubshell. The PowerShift system offers the range benefits of a 2x drivetrain, with the simplicity and aero benefits of a 1x system.

Tyre size: Aero optimized for 28-30mm tyres; work well with 28mm up to 45mm.

€1,649
Limited Stock. Available Now.Items are selected to ship from us in the week stated. Delivery time is 3-6 days*

We will ask for Axle info after checkout.

All import duties, taxes and handling costs are covered by us.

Order ETA 3-6 days*
Our wheels are in high demand, don't miss out. Order now.

*If shown in stock

H_CARE

FREE LIFETIME CRASH REPLACEMENT

To ensure you're not out of pocket should the worst happen. Learn more.

The Purpose _

The Purpose _

HUNT’s wide and stable, wind tunnel-proven aerodynamic wheelset is now available with the groundbreaking Classified Powershift-ready rear hub shell to create a versatile all-round road wheel system for those seeking every benefit that modern cycling techonology can offer.

NOTE:The Classified Powershift internal system and electronics must be supplied by select Classified dealers. This wheelset does not contain the complete system. The rear wheel is delivered with the Classified hub shell, without the Powershift hub internals. Please contact our Rider Experience team with any questions.

Full Specs _

Rims
Wind tunnel tested, aerodynamically optimised for 25-28c tyresDisc-specific tubeless-ready profileH-lock bead-seat up-kicks for easy and secure tubeless installationUnidirectional T24/30 carbon fibre with 3K weave re-enforced spoke holes35mm outer and 22.5mm inner width48mm depthMatt black base finished with matt white contrasting graphics.
  • Wind tunnel tested, aerodynamically optimised for 25-28c tyres
  • Disc-specific tubeless-ready profile
  • H-lock bead-seat up-kicks for easy and secure tubeless installation
  • Unidirectional T24/30 carbon fibre with 3K weave re-enforced spoke holes
  • 35mm outer and 22.5mm inner width
  • 48mm depth
  • Matt black base finished with matt white contrasting graphics.
Nipples
Brass for anti-corrosion resistance.16mm length with washer for a strong connection to the spoke added durability.14 gauge.Black anodized finish.
  • Brass for anti-corrosion resistance.
  • 16mm length with washer for a strong connection to the spoke added durability.
  • 14 gauge.
  • Black anodized finish.
Spokes
Pillar Wing 20 with Aerofoil profile20 front and 24 rear laced 2 cross.Aero Butted 2.0-2.2/0.95-2.0 then PSR section is 2.2.Straight-pull for excellent torsional strength and direct power transferCold drawn from high grade T302 (18/10) stainless steel wire by Sandvik SwedenPatented Pillar Spoke Re-enforcement, butted again just before the spoke head providing more durability in high stress area.Black stainless treatment
  • Pillar Wing 20 with Aerofoil profile
  • 20 front and 24 rear laced 2 cross.
  • Aero Butted 2.0-2.2/0.95-2.0 then PSR section is 2.2.
  • Straight-pull for excellent torsional strength and direct power transfer
  • Cold drawn from high grade T302 (18/10) stainless steel wire by Sandvik Sweden
  • Patented Pillar Spoke Re-enforcement, butted again just before the spoke head providing more durability in high stress area.
  • Black stainless treatment
Axle Sizes
These wheels are available with the following disc brake road bike axle adapter sizes. We fit the axles you need, just complete the simple form shown after checkout:Front: 12x100mm Thru-Axle, 9x100mm Thru-Axle, Quick Release 9x100mmRear: 12x142mm Thru-Axle OnlyIf you are unsure what size your axles are don't worry it also includes the option to tell us your bike model and we will find out and then fit the correct axles, plus we're happy to change them later at our cost if you don't quite get it right. Please note; this form is shown after you have completed your order.

These wheels are available with the following disc brake road bike axle adapter sizes. We fit the axles you need, just complete the simple form shown after checkout:

  • Front: 12x100mm Thru-Axle, 9x100mm Thru-Axle, Quick Release 9x100mm
  • Rear: 12x142mm Thru-Axle Only

If you are unsure what size your axles are don't worry it also includes the option to tell us your bike model and we will find out and then fit the correct axles, plus we're happy to change them later at our cost if you don't quite get it right. Please note; this form is shown after you have completed your order.

Tyres Info
HUNT recommends a 25-28mm tyre for best performance, tyre widths between 23mm and 50mm are also safe to use.  Note: best performance is usually gained by using tyre pressures lower than the maximum, you can see our blog post about this, read here. Tubeless-ready for lower weight and rolling resistance. You must not exceed the maximum tyre pressure limits set out in the table below or the maximum limit set by your tyre manufacturer if this is lower.
  • HUNT recommends a 25-28mm tyre for best performance, tyre widths between 23mm and 50mm are also safe to use.
  • Note: best performance is usually gained by using tyre pressures lower than the maximum, you can see our blog post about this, read here.
  • Tubeless-ready for lower weight and rolling resistance.
  • You must not exceed the maximum tyre pressure limits set out in the table below or the maximum limit set by your tyre manufacturer if this is lower.
Front Hub
Forged and CNC’d 6061-T6 heat treated aluminium alloy body.7075-T6 aluminium alloy axles.Polished anodized black finish with laser graphics.Center-lock disc mount. If you require a 6 bolt adaptor you can purchase separately here
  • Forged and CNC’d 6061-T6 heat treated aluminium alloy body.
  • 7075-T6 aluminium alloy axles.
  • Polished anodized black finish with laser graphics.
  • Center-lock disc mount. If you require a 6 bolt adaptor you can purchase separately here
Bearings
High-grade Japanese EZO bearings.Incredibly fast rolling.
  • High-grade Japanese EZO bearings.
  • Incredibly fast rolling.

HIGH SPECIFICATION COMPONENTS _

PATENTED LIMITLESS TECHNOLOGY

In order to create the most aerodynamic & stable shape for the tyre, a rim bed of 22.5mm is needed. With the tyre profile this creates, the ideal shape of the rim curves out to an external width of 35mm. To overcome the weight penalty associated with this, we use a (non-structural) low density expanding polymer insert, inside a channel carved out during pre-preg. This is bonded to the carbon during the curing process, resulting in an exceptionally strong bond. The density of carbon is 1.6g per cubic centimetre, whereas the polymer insert weighs just 0.7g per cubic centimetre, resulting in a (rotational) mass loss of just over 50g per rim. This patented technology enables us to consider the limits of material properties, and smash right past them.

BEARINGS

The heart of any wheel. Investing in them makes huge sense. We use high-grade Japanese EZO bearings precision smooth-rolling sealed cartridge bearings.

CLASSIFIED REAR HUB

Classified rear hubshell has been fitted to this wheelset by hand, and will arrive ready to fit a Powershift hub system.

SPOKES

Despite designing a wheelset with aerodynamic supremacy in mind, serviceability and usability has always been a core philosophy of how we put wheels together. External spoke nipples are absolutely the right choice with this in mind, especially when running tubeless tires as you would have to remove the tubeless tape to access the nipples were they to be internal.

RIM BED

Patented LIMITLESS technology allows for a 22.5mm rim bed and a huge 34.5mm external rim width, meaning the rim sits far wider than the tyre for aerodynamic superiority.

WEIGHT

1,501g (Including Powershift rear hub shell)

TYRES

Optimised aerodynamically for a Schwalbe Pro One 28c, but compatible with any tubeless or clincher tyre from 23 up to 45c.

What's in the box _

  • HUNT Black Shield tubeless tape fitted to wheels.
  • 60mm Tubeless Valves
  • Spare of each spoke plus nipples
  • Quality control card signed by your wheel builder

Items included in the box: A spare of each spoke and two tubeless valves

WARRANTY_

These wheels come with H_CARE (Free Lifetime Crash Replacement) for the first owners. Read all about it here.

A full 3 years from purchase date warranty is offered to the original purchaser only on all HUNT wheels against material or workmanship defects, please click here to read full details.

All HUNT wheels models have to pass our harsh cobbled-rolling-road tests for rider weight limits, please see here for more details. Max system weight 125kg (system weight – total weight of fully kitted up rider, bike and luggage). If a rider is over 105Kgs then an experienced bike mechanic should check the wheel regularly.
