HUNT 42 Limitless Gravel Aero Wheelset
Hunt Bike Wheels 42 Limitless Gravel Wheelset
Hunt Bike Wheels 42 Limitless Gravel Wheelset
<h1>WIND TUNNEL TESTED</h1><i> Developed by HUNT's in-house engineering team, with years in the wind tunnel spent testing every last detail. We've left no stone unturned in designing this wheelset from the ground up to be very fastest in the world within its class.</i>
<h1>Wind tunnel proven</h1><i>Proven to offer the lowest aerodynamic drag among tested gravel-specific wheelsets under 50mm depth, offering the rider up to .12 Watt savings over renowned competitors, and 16.8 Watt savings over non-aero gravel wheels</i>
<h1>Tyre Compatability</h1><i>Designed around a 24.5mm internal rim width optimized aerodynamically for 38-42c gravel tyres but will work with any tyre up to 54c. Also works excellently with clincher tyres and tubes. They feature a hooked tyre retention design and are both fully ETRTO-compatible and tubeless-ready.</i>
<h1>Wing Spokes</h1><i>After considerable testing across multiple spoke types (including analysis against competitor spokes), we found that the aerofoil profile of Pillar's Wing spokes offer even further aerodynamic advantages over flat/bladed options.</i>
<h1>Patented Limitless Technology</h1><i>In order to create the most aerodynamic & stable shape for the tyre, a rim bed of 24.5mm is needed. With the tire profile this creates, the ideal shape of the rim curves out to an external width of 36mm. To overcome the weight penalty associated with this, we use a (non-structural) low density expanding polymer insert, inside a channel carved out during pre-preg.</i>
<h1>Patented Limitless Technology</h1><i>This is bonded to the carbon during the curing process, resulting in an exceptionally strong bond. The density of carbon is 1.6g per cubic centimeter, whereas the polymer inserts weigh just 0.7g per cubic centimeter, resulting in a (rotational) mass loss of just over 50g per rim. This patented technology enables us to consider the limits of material properties, and smash right past them. </i>
<h1>CeramicSpeed Coated Bearings</h1><i>The 42 Limitless Gravel Disc will come fully equipped with CeramicSpeed's coated bearings are a further 75% tougher than their standard hardened steel races, and it's this enhanced strength that makes for a bearing solution that boasts an average lifetime 7.5 times longer than other non-coated solutions. CeramicSpeed’s coated bearing solutions are designed and tested extensively to ensure that failure due to corrosion is negligible.</i>
Detailed image of the 54 UD Carbon Spoke Disc rear hub, featuring CeramicSpeed bearings
<h1>Nipples</h1><i>Despite designing a wheelset with aerodynamic supremacy in mind, serviceability and usability has always been a core philosophy of how we put wheels together. External spoke nipples are absolutely the right choice with this in mind, especially when running tubeless tires as you would have to remove the tubeless tape to access the nipples were, they to be internal.</i>
<h1>In the Box</h1><ul><li>HUNT Black Shield tubeless tape fitted to wheels.</li><li>The axle adapters needed for your bike, just fill in the simple form shown after order completion, the form is also included in your order confirmation page.</li><li>Cassette spacer for 8/9/10 speed</li><li>Tubeless Valves</li><li>Spare of each spoke plus nipples</li><li>Quality control card signed by your wheel builder</li></ul>
Hunt Bike Wheels 42 Limitless Gravel Wheelset
Hunt Bike Wheels 42 Limitless Gravel Wheelset
<h1>WIND TUNNEL TESTED</h1><i> Developed by HUNT's in-house engineering team, with years in the wind tunnel spent testing every last detail. We've left no stone unturned in designing this wheelset from the ground up to be very fastest in the world within its class.</i>
<h1>Wind tunnel proven</h1><i>Proven to offer the lowest aerodynamic drag among tested gravel-specific wheelsets under 50mm depth, offering the rider up to .12 Watt savings over renowned competitors, and 16.8 Watt savings over non-aero gravel wheels</i>
<h1>Tyre Compatability</h1><i>Designed around a 24.5mm internal rim width optimized aerodynamically for 38-42c gravel tyres but will work with any tyre up to 54c. Also works excellently with clincher tyres and tubes. They feature a hooked tyre retention design and are both fully ETRTO-compatible and tubeless-ready.</i>
<h1>Wing Spokes</h1><i>After considerable testing across multiple spoke types (including analysis against competitor spokes), we found that the aerofoil profile of Pillar's Wing spokes offer even further aerodynamic advantages over flat/bladed options.</i>
<h1>Patented Limitless Technology</h1><i>In order to create the most aerodynamic & stable shape for the tyre, a rim bed of 24.5mm is needed. With the tire profile this creates, the ideal shape of the rim curves out to an external width of 36mm. To overcome the weight penalty associated with this, we use a (non-structural) low density expanding polymer insert, inside a channel carved out during pre-preg.</i>
<h1>Patented Limitless Technology</h1><i>This is bonded to the carbon during the curing process, resulting in an exceptionally strong bond. The density of carbon is 1.6g per cubic centimeter, whereas the polymer inserts weigh just 0.7g per cubic centimeter, resulting in a (rotational) mass loss of just over 50g per rim. This patented technology enables us to consider the limits of material properties, and smash right past them. </i>
<h1>CeramicSpeed Coated Bearings</h1><i>The 42 Limitless Gravel Disc will come fully equipped with CeramicSpeed's coated bearings are a further 75% tougher than their standard hardened steel races, and it's this enhanced strength that makes for a bearing solution that boasts an average lifetime 7.5 times longer than other non-coated solutions. CeramicSpeed’s coated bearing solutions are designed and tested extensively to ensure that failure due to corrosion is negligible.</i>
Detailed image of the 54 UD Carbon Spoke Disc rear hub, featuring CeramicSpeed bearings
<h1>Nipples</h1><i>Despite designing a wheelset with aerodynamic supremacy in mind, serviceability and usability has always been a core philosophy of how we put wheels together. External spoke nipples are absolutely the right choice with this in mind, especially when running tubeless tires as you would have to remove the tubeless tape to access the nipples were, they to be internal.</i>
<h1>In the Box</h1><ul><li>HUNT Black Shield tubeless tape fitted to wheels.</li><li>The axle adapters needed for your bike, just fill in the simple form shown after order completion, the form is also included in your order confirmation page.</li><li>Cassette spacer for 8/9/10 speed</li><li>Tubeless Valves</li><li>Spare of each spoke plus nipples</li><li>Quality control card signed by your wheel builder</li></ul>
This model is no longer available. Please sign up to our emails to hear about new HUNT product launches.

HUNT 42 Limitless Gravel Aero Wheelset

1548g Depth Width ext Width int size
42 mm 36 mm 25 mm 700c

Engineered from the ground up to be the fastest wheel for today's modern, high-speed gravel races.

Aerodynamically optimized around 38-40c gravel tyres to reduce aerodynamic drag and provide crosswind stability, saving you watts and time, while allowing you to focus on your race, regardless of the wind conditions.

Tyre size: Aero optimized for 40mm tyres; work well with 29mm up to 64mm.

More details Right

The Purpose _

<h1>Wing Spokes</h1><i>After considerable testing across multiple spoke types (including analysis against competitor spokes), we found that the aerofoil profile of Pillar's Wing spokes offer even further aerodynamic advantages over flat/bladed options.</i>

The Purpose _

With the 42 Limitless Gravel Aero, HUNT set out to develop the premier performance gravel wheelset, optimising gravel-specific aerodynamics through patented Limitless technology, and balancing those against another critically important attribute for riders moving fast over inconsistent surfaces: crosswind stability (steering moment).

The recent proliferation of gravel races across the globe means riders are now rethinking their equipment selections and employing aerodynamically designed skinsuits, helmets, frames and wheels. With industry-leading engineering and design talent in-house, HUNT aims to set a new standard for gravel-specific wheel performance.

KEY FEATURES_

Patented Limitless Technology

Designed by HUNT's in-house engineering team, HUNT Limitless Technology delivers industry-leading cross wind stability verified by smooth steering moment data proven in wind tunnel testing. 25mm internal and 36mm external widths, and a 42mm u-shape profile.

<h1>CeramicSpeed Coated Bearings</h1><i>The 42 Limitless Gravel Disc will come fully equipped with CeramicSpeed's coated bearings are a further 75% tougher than their standard hardened steel races, and it's this enhanced strength that makes for a bearing solution that boasts an average lifetime 7.5 times longer than other non-coated solutions. CeramicSpeed’s coated bearing solutions are designed and tested extensively to ensure that failure due to corrosion is negligible.</i>

CeramicSpeed Bearings

Featuring CeramicSpeed's world-renowned low-friction Coated Bearings, designed for off road use. These coated bearings are a further 75% tougher than their standard hardened steel races, and boast an average lifetime 7.5 times longer than other non-coated solutions. EZO bearing option also available.

HUNT wheels being put to the test in the GST wind tunnel in Germany

Wind Tunnel Tested

Proven to offer the lowest aerodynamic drag among tested gravel-specific wheelsets under 50mm depth, offering the rider up to .12 Watt savings over renowned competitors, and 16.8 Watt savings over non-aero gravel wheels.

TECHNOLOGY _

The wind tunnel results depict the performance of HUNT 42 Limitless Gravel Aero wheels among a range of world class aero wheels commonly used in competitive gravel racing. The data suggests that the HUNT 42 Limitless Gravel Aero is the most aerodynamic gravel wheelset, offering the rider a small power gain of 0.05W, or 6 seconds of advantage when compared to the next best ranked offering over the course of a 200-mile race averaging a speed of 32 km/h and power output of 317W (Note: the 3T Discus 45|40 was not available to test, as it was not released to the public when testing occurred).

With the use of patented Limitless construction, HUNT was able to create a wheelset that offers an extremely wide rim profile with a truncated edge (blunted spoke bed) to help airflow remain attached to the system, while maintaining low overall weight and providing day-in and day-out performance and durability on the harshest gravel roads.

See the research white paper for full technical details of our wind tunnel testing methodology, including data/graphs and the full range of wheels we tested against.

Full Specs _

Rims
Wind tunnel tested, aerodynamically optimised for 40mm tyres Hooked H-lock bead-seat up-kicks for easy and secure tubeless installation Unidirectional T24/30 carbon fiber with 3K weave re-enforced spoke holes 36mm outer and 24.5mm inner width 42mm depth Matt black base finished with matt white contrasting graphics
  • Wind tunnel tested, aerodynamically optimised for 40mm tyres
  • Hooked
  • H-lock bead-seat up-kicks for easy and secure tubeless installation
  • Unidirectional T24/30 carbon fiber with 3K weave re-enforced spoke holes
  • 36mm outer and 24.5mm inner width
  • 42mm depth
  • Matt black base finished with matt white contrasting graphics
Spokes
Pillar Wing with Aerofoil 24 front and 24 rear interlaced Aero Butted 2.0-2.2/0.95-2.0 then PSR section is 2.2 Straight-pull for excellent torsional strength and direct power transfer Cold drawn from high grade T302 (18/10) stainless steel wire by Sandvik Sweden Patented Pillar Spoke Re-enforcement, butted again just before the spoke head providing more durability in high stress area Black stainless treatment
  • Pillar Wing with Aerofoil
  • 24 front and 24 rear interlaced
  • Aero Butted 2.0-2.2/0.95-2.0 then PSR section is 2.2
  • Straight-pull for excellent torsional strength and direct power transfer
  • Cold drawn from high grade T302 (18/10) stainless steel wire by Sandvik Sweden
  • Patented Pillar Spoke Re-enforcement, butted again just before the spoke head providing more durability in high stress area
  • Black stainless treatment
Nipples
Alloy square body for external adjustment and square head for easy internal adjustment/tensioning. 16mm length with washer for a strong connection to the spoke added durability 14 gauge Black anodized finish
  • Alloy square body for external adjustment and square head for easy internal adjustment/tensioning.
  • 16mm length with washer for a strong connection to the spoke added durability
  • 14 gauge
  • Black anodized finish
Front Hub
Forged and CNC’d 6066-T6 heat treated aluminum alloy body. 6066-T6 aluminum alloy axles. Center-lock disc mount. If you require a 6 bolt adaptor you can purchase separately here HUNT SPRINT SL Disc straight-pull super-light alloy. Polished anodized black finish with laser graphics.
  • Forged and CNC’d 6066-T6 heat treated aluminum alloy body.
  • 6066-T6 aluminum alloy axles.
  • Center-lock disc mount. If you require a 6 bolt adaptor you can purchase separately here
  • HUNT SPRINT SL Disc straight-pull super-light alloy.
  • Polished anodized black finish with laser graphics.
Rear Hub
7075-T6 heat-treated aluminium alloy freehub body. Steel Spline Insert freehub body reinforcement provides excellent durability against cassette sprocket damage to the freehub often seen on standard alloy freehub bodies. 3x treble-tooth individually leaf sprung pawls with 48 teeth on the ratchet ring for fast 7.5 degree engagement and instant acceleration. All freehub standards accounted for. Hunt Race Season Disc straight-pull super-light alloy. Forged and CNC’d 6061-T6 heat treated aluminium alloy body. 7075-T6 aluminium alloy axles. Center-lock disc mount. If you require a 6 bolt adaptor you can purchase separately here Polished anodized black finish with laser graphics.
  • 7075-T6 heat-treated aluminium alloy freehub body.
  • Steel Spline Insert freehub body reinforcement provides excellent durability against cassette sprocket damage to the freehub often seen on standard alloy freehub bodies.
  • 3x treble-tooth individually leaf sprung pawls with 48 teeth on the ratchet ring for fast 7.5 degree engagement and instant acceleration.
  • All freehub standards accounted for.
  • Hunt Race Season Disc straight-pull super-light alloy.
  • Forged and CNC’d 6061-T6 heat treated aluminium alloy body.
  • 7075-T6 aluminium alloy axles.
  • Center-lock disc mount. If you require a 6 bolt adaptor you can purchase separately here
  • Polished anodized black finish with laser graphics.
Bearings
Industry leading CeramicSpeed ceramic coated bearings. EZO bearing option also available. 75% tougher than their standard hardened steel races, boasting an average lifetime seven and a half times longer than other non-coated solutions CeramicSpeed bearing balls are of the highest quality, featuring the highest achievable surface finish and roundness Life-time warranty (When registered with CeramicSpeed)
  • Industry leading CeramicSpeed ceramic coated bearings. EZO bearing option also available.
  • 75% tougher than their standard hardened steel races, boasting an average lifetime seven and a half times longer than other non-coated solutions
  • CeramicSpeed bearing balls are of the highest quality, featuring the highest achievable surface finish and roundness
  • Life-time warranty (When registered with CeramicSpeed)
Tyres Info
HUNT recommends a 40mm tyre for best performance, tyre widths between 29mm and 64mm are also safe to use.   Note: best performance is usually gained by using tyre pressures lower than the maximum, you can see our blog post about this, read here.  Tubeless-ready for lower weight and rolling resistance.  You must not exceed the maximum tyre pressure limits set out in the table below or the maximum limit set by your tyre manufacturer if this is lower.
  • HUNT recommends a 40mm tyre for best performance, tyre widths between 29mm and 64mm are also safe to use.
  • Note: best performance is usually gained by using tyre pressures lower than the maximum, you can see our blog post about this, read here.
  • Tubeless-ready for lower weight and rolling resistance.
  • You must not exceed the maximum tyre pressure limits set out in the table below or the maximum limit set by your tyre manufacturer if this is lower.
Axle Sizes
These wheels are compatible with the following axle specifications. We fit the axle adapters you need, just complete the simple form shown after checkout: Front: 12x100mm Thru-Axle, 9x100mm Thru-Axle, Quick Release 9x100mm Rear: 12x142mm Thru-Axle, 12x135mm Thru-Axle, 10x135mm Thru-Axle, Quick Release 9x135mm If you are unsure, please do not worry as our form includes the option to tell us your bike model. We will then do our best to support you and fit the correct axle adapters. We may contact you via email if we need further information. Plus, if you don't g Please note; this form is shown after you have completed your order.

These wheels are compatible with the following axle specifications. We fit the axle adapters you need, just complete the simple form shown after checkout:

  • Front: 12x100mm Thru-Axle, 9x100mm Thru-Axle, Quick Release 9x100mm
  • Rear: 12x142mm Thru-Axle, 12x135mm Thru-Axle, 10x135mm Thru-Axle, Quick Release 9x135mm
  • If you are unsure, please do not worry as our form includes the option to tell us your bike model. We will then do our best to support you and fit the correct axle adapters. We may contact you via email if we need further information. Plus, if you don't g Please note; this form is shown after you have completed your order.

HIGH SPECIFICATION COMPONENTS _

<h1>Patented Limitless Technology</h1><i>In order to create the most aerodynamic & stable shape for the tyre, a rim bed of 24.5mm is needed. With the tire profile this creates, the ideal shape of the rim curves out to an external width of 36mm. To overcome the weight penalty associated with this, we use a (non-structural) low density expanding polymer insert, inside a channel carved out during pre-preg.</i>
Patented Limitless Technology

In order to create the most aerodynamic & stable shape for the tyre, a rim bed of 24.5mm is needed. With the tyre profile this creates, the ideal shape of the rim curves out to an external width of 36mm. To overcome the weight penalty associated with this, we use a (non-structural) low density expanding polymer insert, inside a channel carved out during pre-preg.
Wind Tunnel Tested

Developed by HUNT's in-house engineering team, with years in the wind tunnel spent testing every last detail. We've left no stone unturned in designing this wheelset from the ground up to be very fastest in the world within its class.

<h1>Tyre Compatability</h1><i>Designed around a 24.5mm internal rim width optimized aerodynamically for 38-42c gravel tyres but will work with any tyre up to 54c. Also works excellently with clincher tyres and tubes. They feature a hooked tyre retention design and are both fully ETRTO-compatible and tubeless-ready.</i>
Wind Tunnel Proven

Proven to offer the lowest aerodynamic drag among tested gravel-specific wheelsets under 50mm depth, offering the rider up to .12 Watt savings over renowned competitors, and 16.8 Watt savings over non-aero gravel wheels

Hunt Bike Wheels 42 Limitless Gravel Wheelset
Rim Profile

In order to create the most aerodynamic & stable shape for the tyre, a rim bed of 21mm is needed. With the tyre profile this creates, the ideal shape of the rim curves out to an external width of 34mm. To overcome the weight penalty associated with this, we use a (non-structural) low density expanding polymer insert, inside a channel carved out during the production process. This is bonded to the carbon during the curing process, resulting in a uniform and strong bond. The density of carbon is 1.6g per cubic centimetre, whereas the polymer insert weighs just 0.7g per cubic centimetre, resulting in a (rotational) mass loss of just over 50g per rim. This patented technology enables us to consider the limits of material properties, and smash right past them.

<h1>Wing Spokes</h1><i>After considerable testing across multiple spoke types (including analysis against competitor spokes), we found that the aerofoil profile of Pillar's Wing spokes offer even further aerodynamic advantages over flat/bladed options.</i>
Tyre Compatibilty

Designed around a 24.5mm internal rim width optimized aerodynamically for 40mm gravel tyres but will work with any tyre up to 64mm. Also works excellently with clincher tyres and tubes. They feature a hooked tyre retention design and are both fully ETRTO-compatible and tubeless-ready.

<h1>Wing Spokes</h1><i>After considerable testing across multiple spoke types (including analysis against competitor spokes), we found that the aerofoil profile of Pillar's Wing spokes offer even further aerodynamic advantages over flat/bladed options.</i>
Wing Spokes

After considerable testing across multiple spoke types (including analysis against competitor spokes), we found that the aerofoil profile of Pillar's Wing spokes offer even further aerodynamic advantages over flat/bladed options.

What's in the box _

  • HUNT Black Shield tubeless tape fitted to wheels.
  • The axle adapters needed for your bike, just fill in the simple form shown after order completion, the form is also included in your order confirmation page.
  • Cassette spacer for 8/9/10 speed
  • Spare spokes with nipples & washers.
  • 60mm Tubeless Valves
  • Quality control card signed by your wheel builder

The items included in the box: A spare of each spoke and two tubeless valves

WARRANTY_

These wheels come with H_CARE (Free Lifetime Crash Replacement) for the first owners. Read all about it here.

A full 3 years (4 years on CeramicSpeed bearings*) from purchase date warranty is offered to the original purchaser only on all HUNT wheels against material or workmanship defects, please click here to read full details.  *Must be registered with CeramicSpeed.

Stated wheel weights: Our stated wheel weights reflect the wheelset only; without rim tape, tubeless valves or disc brake lock rings, as is industry standard. A 3% variance (lower or higher) in total system weight is normal for wheelset manufacturing.

All HUNT wheels models have to pass our harsh cobbled-rolling-road tests for rider weight limits, please see here for more details. Max system weight 130 kg (system weight – total weight of fully kitted up rider, bike and luggage). If the system is over 105 kgs then an experienced bike mechanic should check the wheel regularly.
